Description

Mellanox® MMA1B00-C100 is a 4-channel, pluggable, QSFP28 optical transceiver, designed for use in 100Gb s Ethernet. This module incorporates Mellanox integrated circuit technology, in order to provide high performance at low power. The transceiver operates over parallel multi-mode (MMF) ribbon fiber, using a nominal wavelength of 850nm, and is SFF-8665 compliant.

The MMA1B00-C100 has a standard QSFP28 connector on the electrical side towards the host system supporting CAUI-4. The optical interface is composed of four optical channels fibers in each direction, intended for a parallel multi-mode optical cable via a standard MPO connector. Each channel fiber operates at signaling rates up to 25.78125 GBd.

The MMA1B00-C100D transceiver has DDM functions implemented for reading the following key parameters with associated warning and alarm thresholds:

-Temperature with warning alarm

-Supply voltage with warning alarm

-Laser bias current

-Transmitted optical power with warning alarm

-Received optical power with warning alarm

Rigorous production testing ensures the best out-of-the-box installation experience, performance, and durability.

• QSFP28 offers better usage with maximum efficiency and convenience
• With 100GBase-SR4 technology, get up to 100Gbps data transfer rate over optical fiber cable
• Provides high performance and flexible solution with 100 Gigabit Ethernet connectivity
• Optical Fiber media support for a dependable and productive connectivity
• Typically used for short distance, multi-mode fiber optic is ideal to carry data and transmit audio video applications within a building
• Hot-pluggable form factor allows hassle-free and easy usage with increased efficiency
• QSFP28 with optical network application usage for reliability and maximum efficiency
